LD-SRS100CXLL-1500
Side single-spindle full servo drive large-spreading nickel-soldering wire winding machine















Technical Parameters：
Wire Size :
0.2 ~ 2.0mm
Flat Wire:
0.05x0.1 ~ 0.7x1.5 mm
Max .Speed :
2800rpm
Main Motor :
AC servo motor750W*2 (Main spindle/tailstock servo synchronous operation)
Winding Width :
400mm
Spreading Motor :
AC servo motor 750W
Spreading Width :
1500mm(Actual working route 1000mm)
Spreading assembly:
Wire feeding angle -25°~25° adjustable
Tension mechanism:
Tension 200g~5kg adjustable
Power :
AC 220V 50/60Hz
Net Weight :
260kgs
Dimensions :
L2400*W700*H1200mm
